Manufacturer: HPE

  • HP DL 360 G10 Primary Riser 869432-001

    HP DL 360 G10 Primary Riser 869432-001

    Primary riser pulled from an HP DL 360 G10 10 Bay server. Compatible with the entire line of 360 G10 servers.

    Notes

    • This is the metal riser cage/bracket assembly, not the PCIe riser board itself. A lot of times the PCB board is included with this part number, but not always.
    • Requires the appropriate DL360 Gen10 PCIe riser card to provide PCIe slots.
    • Used as the primary (left-side) expansion riser assembly in DL360 Gen10 systems.
    • Compatible only with the DL360 Gen10 chassis; it is not intended for DL380 Gen10 or earlier generations.





  • HP DL 360 G10 10 Bay

    HP DL 360 G10 10 Bay

    Compatible Parts

    Additional guides and resources:

    HP DL 360 G10 10 Bay Premium Configuration and Build Guide

  • HP DL 380 G10 Heatsink 873592-001

    HP DL 380 G10 Heatsink 873592-001

    Heatsink pulled from an HP DL 380 G10 server.

    Notes

    • Passive heatsink; relies on the server’s high-airflow fan modules.
    • Compatible only with Gen10 Intel Xeon Scalable platforms using the LGA3647 socket.
    • Not interchangeable with Gen9 or Gen11 heatsinks.
    • HPE also offers higher-performance heatsinks for processors with higher TDP ratings; verify your CPU’s thermal requirements before substituting.
  • HP 561FLR-T 701525-001

    HP 561FLR-T 701525-001

    FlexibleLOM card based on the Intel X540 controller. Compatible with many G9 and G10 servers that have a flexibleLOM slot.

    Notes

    • Dual-port 10 Gigabit Ethernet adapter utilizing the Intel X540 controller.
    • Provides two RJ45 10GBASE-T network ports supporting 100Mb, 1Gb, and 10Gb Ethernet connections.
    • Uses the HPE FlexibleLOM form factor and installs into a compatible FlexibleLOM slot rather than a standard PCIe slot.
    • Requires Category 6 (or better) twisted-pair cabling for 10GbE operation.
    • Commonly deployed for virtualization, software-defined storage, backup networks, and high-bandwidth server connectivity.
    • Compatible with numerous HPE ProLiant Gen8 and Gen9 servers, including the DL360 Gen9, DL380 Gen9, DL560 Gen9, and DL580 Gen9.
    • Supports network teaming, load balancing, and failover when configured with appropriate operating system and network settings.
    • Not compatible with standard PCIe riser slots unless the server specifically supports the FlexibleLOM interface.



    700697-001

  • HP DL 380 G10 M.2 Riser 877946-001

    HP DL 380 G10 M.2 Riser 877946-001

    This is another variation of the riser found in HP DL 380 G10 servers. This one has an M.2 slot.

    Notes

    • PCIe riser board providing two PCIe x8 slots and one PCIe x16 slot, with integrated support for an M.2 storage module.
    • Designed for use in HPE ProLiant DL380 Gen10 servers and is also used in several Gen10 platform variants, including select SimpliVity and Azure Stack systems.
    • Enables installation of PCIe expansion cards such as network adapters, Fibre Channel HBAs, RAID controllers, SAS controllers, NVMe adapters, and an M.2 boot device (with compatible hardware).
    • PCIe slot availability depends on the server configuration. Some slots and features require a second processor to be installed before they become operational.
    • Compatible expansion cards and M.2 devices must meet the server’s physical, power, thermal, and firmware requirements.
